New Design Display Function Disinfectant Booth Face Recognization Thermometer Infrared HealtyOnes Smart Machine
Product composition
Product composition
l liquid crystal display (LCD)
l Face recognition camera
l Human Temperature Measurement Sensor
l Sterilizing nebulizer
l Sensory sensors
l Android Eight Core Drive
l Lacquer hardware case
Shape dimensions
1. standard size 65 cm,35 cm,180 cm. high
2. luxury size 75 cm, long 170 cm, high 200 cm.
3. voltage 220 V.
4. maximum power: standard version 600 W
Deluxe W 1000
5. disinfectant consumption: L/50 person/time
6. tank capacity :20 L
Overview of products
We are in line with the concept of healthy life, do not take germs home design concept, after years of careful research to launch this public health defense temperature and disinfection machine. Hardware system adopts Android operating system, which is convenient for development and integration. Support deep learning visible face and infrared face dual algorithm, support in vivo detection, automatic white light compensation. The mobile phone sweep code automatically turns on the spray function, after 10 seconds automatically stops, the surface sterilization rate reaches more than 99%. The equipment uses dry fog spray technology, good atomization effect, large amount of spray, fine water molecules, instant diffuse, strong adsorption, Sterilize thoroughly without soaking clothes. The fungicides used are pure natural preparations, do not contain chemical raw materials, are currently the safest killing agent, no harm to human skin, respiratory tract and eyes.
2.1. Product function
The exterior design of the one-body machine for temperature measurement and disinfection is exquisite and has rich five functions
1. human body temperature measurement function.
2. the whole body atomization disinfection function (no moisture feeling).
3. face recognition function (grid access control).
4. somatosensory interaction (fun entertainment).
5. advertising machine publicity, regulation publicity.
2.2. Product characteristics
1. equipped with infrared temperature sensor, binocular camera and disinfection atomizer.
2. support visible face, infrared face depth learning algorithm.
3. supports in vivo detection.
4. support infrared temperature detection, detection distance of 0.5-1 m.
5. support recognition under harsh conditions such as dark, weak light and strong light.
6. super capacity, support local alignment.
7. ultra-thin aluminum alloy shell, beautiful and fashionable appearance, metal body, smooth curve design.
8. high quality material selection, friction resistance, antistatic, corrosion resistance, strong stability.
9. has the function of eliminating the residual shadow automatically and protecting the long-term use of LCD screen
10. Self-adaptive black-level extension to enhance the depth-of-field sense of the image
11. Using a professional LCD screen, the video image is brighter and more stereoscopic
12.16.7 M color, the picture is more natural, the fine picture really no tail
13. High reliability and stability with intelligent temperature control, environmental protection and mute, especially suitable for working in harsh environment
14. Over-long life span ,24 hours uninterrupted work up to over 60,000 hours
Product Specification Parameters:
|
Name
|
Temperature measurement and disinfection machine
|
|
Size
|
Size 65 cm,35 cm,180 cm high
|
|
Processor
|
Eight core 3288, main frequency up to 1.8 Ghz
|
|
System
|
Android
|
|
storage
|
16GB EMMC
|
|
memory
|
2GB DDR3
|
|
Display
|
24 inch display
|
|
Atomization
|
Three Point High Pressure Atomization
|
|
Storage
|
10000 pair
|
|
Interactive distance
|
60cm~100cm
|
|
Signal
|
TCP/IP
|
|
Use
|
Gate, Wall mounted
|
|
Operational Tips
|
LCD Screen Tips, Voice Wizard and Lighting Tips
|
|
Voltage
|
DC 12V@4A
|
|
Camera
|
1 1.3 million infrared face ,1 3 million visible face (wide dynamic)
|
|
Functions
|
Body temperature testing, spray disinfection, face recognition, somatosensory interaction, advertising
|
|
Interface
|
RJ45,RS232, Wigan 26/34 Output, relay
|
|
RM
|
infrared face, visible face
|
|
Conditions
|
Working temperature :-20~55℃ Working humidity :25~85%
|
